BatteryProtect 12/24V-100A
From £39.22
RRP £32.05
Compared across 3 retailers
Victron BatteryProtect 12/24V 100A. Disconnects the battery from non-essential loads before it is completely discharged. Features MOSFET switches (ignition proof), over voltage protection, programmable engage/disengage voltages, and Li-ion battery compatibility.
- SKU
- BPR000100400
- Dimensions
- 62x123x120
- Continuous Load Current
- 100A
- Peak Current 30s
- 600A
- Voltage Range
- 6-35V DC
- Power Consumption
- 1.5mA
Price Comparison
| Retailer | Price | Availability | Actions |
|---|---|---|---|
| BMS Technologies | £39.22 Use code V4L5 at checkout for 5% discount | In Stock | Visit Site |
| Powerland | £47.02 | In Stock | Visit Site |
| Callidus | £65.87 | In Stock | Visit Site |
Price History
Not enough price history data available yet. Check back as we collect more pricing information.
Full Specifications
| SKU | BPR000100400 |
|---|---|
| EAN | 8719076021438 |
| Dimensions | 62x123x120 |
| Continuous Load Current | 100A |
| Peak Current 30s | 600A |
| Voltage Range | 6-35V DC |
| Power Consumption | 1.5mA |
| Connection | M8 bolt |
| Alarm Output Delay | 12 seconds |
| Load Disconnect Delay | 90 seconds |
| Operating Temperature | -40 to +50°C |
| IP Rating | IP67 (electronic compartment IP00) |
| Weight Kg | 0.8 |
| Dimensions Mm | 62 x 123 x 120 |
About the BatteryProtect 12/24V-100A
The BatteryProtect disconnects the battery from non-essential loads before it is completely discharged (which would damage the battery) or before it has insufficient power left to crank the engine.
The BatteryProtect is a uni-directional device. It can only deal with current in one direction, so either current to a load, or current from a charger, but not both currents at the same time. Current can only flow from the Battery terminal to the Load terminal.
Features
- Over voltage protection — the load is disconnected whenever the DC voltage exceeds 16V (12V system) or 32V (24V system)
- Ignition proof — uses MOSFET switches instead of relays, so no sparks
- 12/24V auto ranging — automatically detects system voltage
- Programmable — can be set to engage/disengage at several different voltages with seven-segment display
- Delayed alarm output — alarm activates if voltage drops below preset level for more than 12 seconds
- Delayed load disconnect — load disconnects 90 seconds after alarm activation
- Li-ion mode — special setting allows control by VE.Bus BMS
- Low power consumption — only 1.5mA when on
